Sirona Intego - Setting the Brightness, Light Temperature and Sensor Control of the; Plus

64 57 498 D3543
172 D3543.201.01.05.02 08.2016
4Operation Sirona Dental Systems GmbH
4.10Operating light Operating Instructions INTEGO
4.10.4 Setting the brightness, light temperature and sensor
control of the LEDview
PLUS
The operating light is always switched on with the programmed
brightness level. The setting is carried out using the user interface of the
dentist element.
Setting the LEDview
PLUS
on the EasyPad
1. Press and hold the Operating light key on the dentist element (> 2 s).
 The
Brightness operating context is displayed on the EasyPad
screen. The setting focus flashes.
2. Use the left and right arrows on the favorite key pad to adjust the
brightness of the operating light (7 levels). The left arrow key
decreases the brightness, the right arrow key increases it.
3. Confirm your setting with the
2 / Setup favorite key.
 The
Light temperature operating context is displayed on the
EasyPad screen. The setting focus flashes.
4. Use the left and right arrows on the favorite key pad to adjust the light
temperature of the operating light (3 levels). The left arrow key
decreases the light temperature, the right arrow key increases it.
5. Confirm your setting with the
2 / Setup favorite key.
 The
Sensor control operating context is displayed on the
EasyPad screen. The setting focus flashes.
6. Use the left and right arrows on the favorite key pad to adjust the
operating distance of the contactless sensor (5 levels). The left arrow
key decreases the operating distance, the right arrow key increases
it. You can try out the setting directly on the operating light without
leaving the setting program. The setting should be selected so that
the contactless sensor cannot be operated unintentionally. Set the
operating distance to "0" to deactivate the contactless sensor.
7. Confirm your setting with the
2 / Setup favorite key.
 The time is displayed.
1
2
Setup
3
2
Setup
1
2
Setup
3
2
Setup
1
2
Setup
3
2
Setup
