Sirona Intego - Dentist element

64 57 498 D3543
80 D3543.201.01.05.02 08.2016
4Operation Sirona Dental Systems GmbH
4.5Dentist element Operating Instructions INTEGO
4.5
Dentist element
4.5.1 Maximum load capacity
TS dentist element
The maximum load on the TS dentist element without a tray holder is 1 kg
(2.2 lbs).
The maximum load on the TS dentist element with a tray holder is 2 kg
(4.4 lbs). In this case, the maximum load on the dentist element and the
tray is 1 kg (2.2 lbs) each.
CS dentist element
The maximum load on the CS dentist element without a tray holder is
0.5 kg (1.1 lbs).
The maximum load on the CS dentist element with a tray holder is 1.5 kg
(3.3 lbs). In this case, the maximum load on the dentist element is 0.5 kg
(1.1 lbs) and on the tray 1 kg (2.2 lbs).
max.
1 kg
2.2 lbs
+
max.
1 kg
2.2 lbs
max.
2,0 kg
4.4 lbs
max.
2,0 kg
4.4 lbs
max.
2,0 kg
4.4 lbs
max.
1 kg
2.2 lbs
max.
0,5 kg
1.1 lbs
max.
1,5 kg
3.3 lbs
max.
1,5 kg
3.3 lbs
+
max.
1 kg
2.2 lbs
max.
1,5 kg
3.3 lbs
max.
0,5 kg
1.1 lbs
