Sirona Dental Systems GmbH 4Operation
Operating Instructions INTEGO 4.7Water unit
båÖäáëÜ
1. Press the foot pedal and move the water unit slightly upwards.
 The patient chair will move automatically into a position in which
the water unit can be rotated. An acoustic signal will also be
given.
2. Move the water unit up until the stop to the other side of the patient
chair.
 The water unit will snap in automatically.
Re-connecting the tray holder and additional holder
1. If an additional holder on the dentist element is present: remove the
intraoral camera from the additional holder. Remove the screw by
hand and take the additional holder out of the dentist element.
CAUTION
The water unit must snap in the end position.
If the water unit is not locked into position, there is a risk of collisions and
crushing for the patient and user.
➢ Check whether the water unit is snapped in.
