Section04ENGINE
Subsection 03 (MAGNETO SYSTEM)
MAGNETO SYSTEM
A33E0MT
To regulator
Silastic 732
Loctite 243
22 Nm
(195 lbfin)
Loctite 243
125 Nm
(92 lbfft)
1
Air sensor
DPM
To main harness
To main harness
2
Loctite 648
7
3
4
5
RER
models
Sikaflex 255
6
mmr2004-Rev 121
