Ski-Doo REV Series Shop Manual

Section 11 TECHNICAL DATA
Subsection 03 (VEHICLES)
VEHICLES
GSX Sport
GSX 500 SS Sport, GSX 600 HO Sport and GSX 600 HO SDI Sport
500 SS 600 HO 600 HO SDI
Country CAN/U.S. CAN/U.S. CAN/U.S.
DRIVE
Chain drive ratio 22/43
Pitch in 3/8
Chain
Type/links qty/plate qty Silent 74/13
Type TRA III
Clutch engagement RPM 3800 ± 100
Spring color Green/white Violet/Blue
Spring length mm (in) 110.7 (4.358) 114.6 (4.5)
Weight —
Block —
Cap —
Pin Solid (P/N 417 004 308)
Ramp 412 410
Drive pulley
Calibration
Screw position 3
Type Formula VSA-R HPV VSA
Spring preload 0Driven pulley
Cam angle 44° 47/44°
Pulley distance Z mm (in) 19.0 ± 0.5 (.748 ± .02) 20.0 ± 0.5 (.787 ± .02)
X mm (in) 37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y–X MIN.-MAX. mm (in) 0.82 ± 0.75 (.0032 ± .0030)
Drive belt part number (P/N) 417 300 197
Drive belt width
(5)
Wear limit mm (in) 33.35 (1.313)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force
(1)
kg (lbf) 11.34 (25)
Width mm (in) 381 (15)
Length mm (in) 3074 (121)
Deflection mm (in) 30 to 35 (1.181 to 1.378)
Track
Adjustment
Force
(2)
kg (lbf) 7.3 (16)
Track SC–10 III
Suspension type
Ski R.A.S. A-arm
ELECTRICAL
Battery 12 V, 18 A•h
Headlamp W 60/55 (H4)
Taillight and stoplight W 8/27
Tachometer and speedometer bulbs W 2x3
Fuel and temperature gauge bulbs W —
mmr2004-Rev 379

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
