Ski-Doo REV Series Shop Manual

Section 06 TRANSMISSION
Subsection 02 (DRIVE PULLEY)
DRIVE PULLEY
TRA III
All REV Series Models
NOTE: These are lubrication free drive pulleys. Always refer to appropriate parts catalog for replacement
part. Most parts of TRA III are not interchangeable with those of the TRA.
A33D16U
95 Nm
(70 lbfft)
31
Loctite
271
30
10 Nm
(89 lbfin)
28
25
26
27
22
21
20
19
16 Nm
(142 lbf in )
For 793 HO
23
25
24
18
7
793 HO
6
5
Electric start
models only
27 Nm
(20 lbfft)
6
593/HO/SDI
12
12
11
15
14
16
10 Nm
(88 lbf in )
9
14
16
12 Nm
(106 lbf
in )
1
2
9
17
17
25 Nm
(18 lbfft)
For 593/HO/SDI
mmr2004-Rev 215
