Ski-Doo REV Series Shop Manual

Section 06 TRANSMISSION
Subsection 02 (DRIVE PULLEY)
To Adjust:
Just loosen locking nut enough to pull calibration
screw
partially
out and adjust to desired position.
Do not completely remove the locking nut. Torque
lockingnutsto10N•m(89lbf•in).
CAUTION: Do not completely remove calibra-
tion screw otherwise its inside washer will fall
off.
CAUTION: Always adjust all 3 calibration
screws and make sure they are all set at the
same number.
A16D0HA
1
TYPICAL
1. Loosen just enough to permit rotating of calibration screw
mmr2004-Rev 225

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
