Section11TECHNICALDATA
Subsection 02 (ENGINES)
Summit
Summit 600 HO Adrenaline and Summit 600 HO X
600 HO Adrenaline 600 HO Adrenaline 600 HO X
Country CAN/U.S. EUROPE CAN/U.S.
Engine Type 593 HO
FUEL SYSTEM
Carburetor/throttle body type PTO/MAG TM40 – B298
Main jet PTO/MAG 380
Needle jet PTO/MAG P-0
Pilot jet PTO/MAG 17.5
Needle identification PTO/MAG 9DGk11–58
Clip position PTO/MAG 3
Slide cut-away 2.0
Float adjustment mm (in) —
Air or pilot screw adjustment ±1/16turn 1.5
Idle speed ± 200 RPM 1600
Gas type Unleaded
Pump octane number 87 (R+M)/2 or higher
Gas/oil ratio Injection
COOLING SYSTEM
Type Liquid
Deflection mm (in) —
Axial fan belt adjustment
Force kg (lbf) —
Thermostat opening temperature °C (°F) 42 (108)
Radiator cap opening pressure kPa (PSI) 90 (13)
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw
(7)
Exhaust manifold nuts or bolts 22 N•m (16 lbf•ft)
Magneto ring nut 125 N•m (92 lbf•ft)
M6 9N•m(80lbf•in)
Crankcase nuts or screws
M8 29 N•m (21 lbf•ft)
Crankcase/engine support nuts or screws 35 N•m (26 lbf•ft)
Cylinder head screws 29 N•m (21 lbf•ft)
Crankcase/cylinder nuts or screws 40 N•m (30 lbf•ft)
Axial fan shaft nut —
374 mmr2004-Rev
