Ski-Doo REV Series Shop Manual

Section 11 TECHNICAL DATA
Subsection 03 (VEHICLES)
GSX Limited
GSX 600 HO SDI Limited and GSX 800 HO Limited
600 HO SDI 800 HO
Country CAN/U.S. CAN/U.S.
DRIVE
Chain drive ratio 22/43 26/45
Pitch in 3/8
Chain
Type/links qty/plate qty Silent 74/13 Silent 76/13
Type TRA III
Clutch engagement RPM 3800 ± 100 3600 ± 100
Spring color Violet/Blue Blue/Green
Spring length mm (in) 114.6 (4.5) 105.7 (4.161)
Weight —
Block —
Cap —
Pin Solid (P/N 417 004 308) Solid (P/N 417 222 594)
Ramp 410 414
Drive pulley
Calibration
Screw position 3
Type HPV VSA
Spring preload 0Driven pulley
Cam angle 47/44° 50/40°
Pulley distance Z mm (in) 20.0 ± 0.5 (.787 ± .02)
X mm (in) 37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y–X MIN.-MAX. mm (in) 0.82 ± 0.75 (.032 ± .030)
Drive belt part number (P/N) 417 300 197 417 300 166
Drive belt width
(5)
Wear limit mm (in) 33.35 (1.313) 34.7 (1.366)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force
(1)
kg (lbf) 11.34 (25) 11.30 (24.912)
Width mm (in) 381 (15)
Length mm (in) 3074 (121)
Deflection mm (in) 30 to 35 (1.181 to 1.378)
Track
Adjustment
Force
(2)
kg (lbf) 7.3 (16)
Track SC–10 III
Suspension type
Ski R.A.S. A-arm
mmr2004-Rev 381

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
