Ski-Doo REV Series Shop Manual

Section 11 TECHNICAL DATA
Subsection 03 (VEHICLES)
MXZ
MXZ 500 SS Adrenaline and MXZ 500 SS Trail
500 SS
Adrenaline
500 SS Trail 500 SS Trail
Country CAN/U.S. CAN/U.S. EUROPE
DRIVE
Chain drive ratio 22/43
Pitch in 3/8
Chain
Type/links qty/plate qty Silent 74/13
Type TRA III
Clutch engagement RPM 3800 ± 100
Spring color Green/white
Spring length mm (in) 110.7 (4.358)
Weight —
Block —
Cap —
Pin Solid (P/N 417 004 308)
Ramp 412
Drive pulley
Calibration
Screw position 3
Type Formula VSA-R
8 ± 0.7 (17.6 ± 1.5)
(8)
Spring preload kg (lbf) 0
0
0Driven pulley
Cam angle 44°
Pulley distance Z mm (in) 19.0 ± 0.5 (.748 ± .02)
X mm (in) 37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y–X MIN.-MAX. mm (in) 0.82 ± 0.75 (.0032 ± .0030)
Drive belt part number (P/N) 417 300 197
Drive belt width
(5)
Wear limit mm (in) 33.35 (1.313)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force
(1)
kg (lbf) 11.34 (25)
Width mm (in) 381 (15)
Length mm (in) 3074 (121)
Deflection mm (in) 30 to 35 (1.181 to 1.378)
Track
Adjustment
Force
(2)
kg (lbf) 7.3 (16)
Track SC–10 III
Suspension type
Ski R.A.S. A-arm
ELECTRICAL
Battery (if so equipped) 12 V, 18 A•h —
Headlamp W 60/55 (H4)
Taillight and stoplight W 8/27
Tachometer and speedometer bulbs W 2x3
Fuel and temperature gauge bulbs W —
mmr2004-Rev 383

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
