Section 11 TECHNICAL DATA
Subsection 03 (VEHICLES)
Summit 800 HO
Summit 800 HO Highmark, Summit 800 HO Highmark X
and Summit 800 HO Highmark Xtrem
Highmark Highmark X Highmark Xtrem
Country CAN/U.S. CAN/U.S. CAN/U.S.
DRIVE
Chain drive ratio 19/45 19/43
Pitch in 3/8
Chain
Type/links qty/plate qty Silent 74/13 Silent 72/13
Type TRA III
Clutch engagement RPM 3800 ± 100
Spring color Violet/Yellow
Spring length mm (in) 157.9 (6.217)
Weight —
Block —
Cap —
Pin Thread Pin (P/N 417 222 707)
Ramp 415
Drive pulley
Calibration
Screw position 1
Type HPV VSA
Spring preload kg (lbf) 0Driven pulley
Cam angle 44° 44°/40°
Pulley distance Z mm (in) 20.0 ± 0.5 (.787 ± .02)
X mm (in) 37.0 ± 0.5 (1.457 ± 0.2)
Offset
Y–X MIN.-MAX. mm (in) 0.82 ± 0.75 (.0032 ± .0030)
Drive belt part number (P/N) 417 300 166
Drive belt width
(5)
Wear limit mm (in) 34.70 (1.366)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force
(1)
kg (lbf) 11.3 (25)
Width mm (in) 406 (16)
Length mm (in) 3648 (144) 4038 (159)
Deflection mm (in) 30 to 35 (1.181 to 1.378)
Track
Adjustment
Force
(2)
kg (lbf) 7.3 (16)
Track SC–10
Suspension type
Ski R.A.S. A-arm
ELECTRICAL
Battery —
Headlamp W 60/55 (H4)
Taillight and stoplight W 8/27
Tachometer and speedometer bulbs W 2x3
Fuel and temperature gauge bulbs W —
Starter solenoid (with electric starter) A —
Fuse
Fuel level sensor A —
CAPACITIES
mmr2004-Rev 405
