Sony XVS Series

109
• When separate edge is enabled
The left, right, top, and bottom border or outline
widths can be adjusted independently. The separate
edge function is only available when luminance key,
linear key, color vector key, or chroma key is selected
as the key type.
When drop border or shadow is selected
When emboss is selected
a) The Density adjustment only affects the key edge. This can be
adjusted separately from key Density, and if key Density is set to
0.00, only the embossed edge effect can be applied.
If emboss is selected, adjust the edge fill in step 6.
4 In the <Edge Fill> group, select the edge fill signal.
Utility 1 Bus: Signal selected on the utility 1 bus
Matte: Signal from dedicated color matte generator.
When [Matte] is selected, adjust color 1 using the
following parameters.
When the edge type is outline, in place of the edge fill
signal, the selected key fill signal fills the outline, and
the background fills all areas other than the outline.
5 Depending on the selection in step 4, carry out the
following operation.
When [Utility 1 Bus] is selected: On the cross-point
control block, press delegation button [UTL1] on
the cross-point pad and select a signal using the
cross-point buttons in the 1st row/2nd row.
• On the cross-point control block in key/AUX bus
delegation mode, press the [UTIL1] button in the 1st
row and select a signal using the cross-point buttons
in the 2nd row.
• You can assign the utility 1 bus using the [UTIL]
button on the cross-point pad of the cross-point
control block (see page 73).
• You can assign a utility 1 bus delegation button to
the 1st row or 2nd row of the AUX bus control block
(AUX bus operation mode) in the Setup menu (see
page 382).
When [Matte] is selected: Press [Matte Adjust] to
open the Matte Adjust menu (1112.1), and select
[Flat Color] (single color) or [Mix Color] (2-color
mix) in the <Edge Matte> group.
If [Mix Color] is selected, set the color mixing (see
page 110).
If [Flat Color] is selected, adjust color 1 using the
following parameters.
6 If the edge type is emboss, adjust the color in the
<Emboss Fill> group.
When adjusting color 1 and 2, select [Matte 1] and
[Matte 2], respectively, then adjust the following
parameters.
7 To soften the edge, select [Soft Edge] and set the
following parameter.
When normal is selected for edge type, [Key Drop]
must be enabled beforehand to use [Soft Edge].
3DensityDensity
No. Parameter Adjustment
1 Top Top edge width
2 Left Left edge width
3 Right Right edge width
4 Bottom Bottom edge width
5DensityDensity
No. Parameter Adjustment
1Width Width
2 Position Position
3DensityDensity
No. Parameter Adjustment
1Width Width
2 Position Position
3Density
a)
Density
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
No. Parameter Adjustment
Notes
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
No. Parameter Adjustment
1 Soft Edge softness
Note
