Sony XVS Series

150
Modifying a DME wipe pattern edge (Edge)
1 Open the M/E-1 >DME Wipe >Edge/Direction menu
(1164).
2 In the <Ch Select> group, select the target channels.
For a pattern in 1-channel mode: Select [1st Ch].
For a pattern in 2-channel mode or 3-channel
mode: Select the corresponding channels. You
can select more than one channel at the same time.
3 In the <Edge> group, select the edge type.
Border: Border
Soft Border: Soft border
4 Depending on the selection in step 3, set the following
parameters.
When [Border] is selected
When [Soft Border] is selected
Display indications when multiple channels are
selected at the same time
The parameter setting value display shows the settings
of the lowest-numbered channel. When you adjust the
settings, this adjusts the settings on the other channels
by the same amount.
Setting the DME wipe pattern position
(Positioner)
1 Open the M/E-1 >DME Wipe >Modify menu (1165).
2 In the <Ch Select> group, select the target channels.
For a pattern in 1-channel mode: Select [1st Ch].
For a pattern in 2-channel mode: Select the
corresponding channels. You can select more than
one channel at the same time.
3 In the <Position> group, press [Position], turning it on.
4 Set the following parameters.
Display indications when multiple channels are
selected at the same time
The parameter setting value display shows the settings
of the lowest-numbered channel. When you adjust the
settings, this adjusts the settings on the other channels
by the same amount.
To return the DME wipe pattern position to the
center of the screen
In the <Position> group, press [Center].
Displaying/moving the DME wipe pattern
position
1 Open the M/E-1 >DME Wipe >Modify menu (1165).
In the <Position Select> group, [Top Left], [Top
Right], [Bottom Left], or [Bottom Right] is lit to
indicate the current display position of the DME wipe
pattern.
2 In the <Position> group, press [Position], turning it on.
3 In the <Ch Select> group, select the target channels.
For a pattern in 1-channel mode: Select [1st Ch].
For a pattern in 2-channel mode: Select the
corresponding channels. You can select more than
one channel at the same time.
4 In the <Position Select> group, press the button for the
move destination, turning it on.
The DME wipe pattern displayed on the screen moves
to the position of the specified button.
Moving the DME wipe pattern to a relative
position
In 2-channel mode, there are also patterns that can move to
a relative position.
1 Open the M/E-1 >DME Wipe >Modify menu (1165).
2 In the <Ch Select> group, select multiple target
channels.
3 In the <Position> group, press [Position], turning it on.
No. Parameter Adjustment
1 Width Border width
3 Luminance Luminance of border color
4 Saturation Saturation
5Hue Hue
No. Parameter Adjustment
1 Width Border width
2 Inner Soft Degree of softness inside the
border
3 Luminance Luminance of border color
4 Saturation Saturation
5Hue Hue
No. Parameter Adjustment
1 H Horizontal position
2 V Vertical position
