4 Set the following parameters.
Setting the DME wipe pattern size (Size)
1 Open the M/E-1 >DME Wipe >Modify menu (1165).
2 In the <Ch Select> group, select the target channels.
For a pattern in 1-channel mode: Select [1st Ch].
For a pattern in 2-channel mode: Select the
corresponding channels. You can select more than
one channel at the same time.
3 Press [Size], turning it on.
4 Set the following parameter.
a) 100% indicates the unchanged size state.
Display indications when multiple channels are
selected at the same time
The parameter setting value display shows the settings
of the lowest-numbered channel. When you adjust the
settings, this adjusts the settings on the other channels
by the same amount.
Adjusting the DME wipe pattern cropping
(Crop)
1 Open the M/E-1 >DME Wipe >Modify menu (1165).
2 In the <Ch Select> group, select the target channels.
For a pattern in 1-channel mode: Select [1st Ch].
For a pattern in 2-channel mode or 3-channel
mode: Select the corresponding channels. You
can select more than one channel at the same time.
For some patterns, the <Ch Select> group
selection is fixed and requires no setting.
3 In the <Crop Mode> group, press [Crop], turning it on.
4 Set the following parameters.
Display indications when multiple channels are
selected at the same time
The parameter setting value display shows the settings
of the lowest-numbered channel. When you adjust the
settings, this adjusts the settings on the other channels
by the same amount.
To crop to 4:3 aspect ratio in 16:9 mode
In the <Crop Mode> group, press [4:3 Crop].
To set the action when a DME wipe crop
transition is executed
1 Open the M/E-1 >DME Wipe >Modify menu (1165).
2 In the <Ch Select> group, select the target channels.
For a pattern in 1-channel mode: Select [1st Ch].
For a pattern in 2-channel mode or 3-channel
mode: Select the corresponding channels. You
can select more than one channel at the same time.
3 In the <Crop Mode> group, press [Crop], turning it on.
4 In the <Crop Mode> group, press [Remove From
Begin].
The Remove From Begin menu (1165.1) appears.
5 In the <Crop Transition> group, select the execution
mode for the DME wipe crop transition.
Cut: Cut mode. The cropping does not change during
the transition, but at the end point of the transition
the cropping is removed (enlarges).
Last 5%: The cropping is maintained for the first 95%
of the transition, and is progressively removed
during the last 5% of the transition (enlarges).
Linear: The cropping is removed linearly from the
start of the transition through the whole course of
the transition (enlarges).
No. Parameter Adjustment
4 Relative H Relative movement in the
horizontal direction
5 Relative V Relative movement in the vertical
direction
No. Parameter Adjustment
1 Size Effect size
a)
Parameter group [1/2]
No. Parameter Adjustment
1 H Crop the left and right of the image
2 V Crop the top and bottom of the
3 All Crop the top, bottom, left, and right
of the image
Parameter group [2/2]
No. Parameter Adjustment
1 Top Crop the top of the image
2 Left Crop the left of the image
3 Right Crop the right of the image
4 Bottom Crop the bottom of the image
