Sony XVS Series

248
4 In the <Spot Mode> group, select the type of light
source (see page 245)
.
Parallel: Parallel light source The direction can be set.
Point: Point light source The position can be set.
Line: Line light source The position and angle can be
set.
Whole: Non-directional light source which
illuminates the whole image
5 Set the following parameters, according to the selected
light source type.
When [Parallel] is selected
When [Point] is selected
When [Line] is selected
a) Minus moves counterclockwise, plus moves clockwise.
b) Minus moves left, plus moves right.
c) Minus moves down, plus moves up.
d) Minus moves forward, plus moves toward the rear.
6 In the <Axis Select> group, select the space in which
to place the light source.
Source: Place the light source in source space. The
spotlight moves when the image moves.
Target: Place the light source in target space. The
spotlight does not move, even when the image
moves.
For details about the space in which to place the light
source, see “Linking and unlinking image and
spotlight” (page 245).
To set a test sphere
1 In the Light 1 menu (4156.3), press [Test Sphere],
turning it on.
A test sphere effect appears on the surface of the
image.
2 Set the following parameter.
a) Light appears from Z direction. At –100.00 the light is directed
toward the rear, at +100.00 the whole image is lit like a flat effect.
To set the illuminated area
In the <Area Select> group of the Light 1 menu (4156.3),
select one of the following.
FRGD: The light strikes the image foreground.
BKGD: The light strikes the image background.
Both: The light strikes both the image foreground and
background.
For details about the illuminated area, see “Selecting the
illuminated area” (page 245).
• When [Multiply] is selected in the <Fill Blending
Mode> group of the Light Color Adjust menu (4156.4)
(see page 249), the lighting effect is not applied to the
background, even if [BKGD] or [Both] is selected.
• When [Brilliancy] is set to 100.0 in the <Fill Source>
group of the Light Color Adjust menu (4156.4) (see
page 249), the lighting effect is not applied to the
background, even if [BKGD] or [Both] is selected.
• When the global effect combiner is set to [Mix] or
[Depth], the lighting effect is not applied to the
background, even if [BKGD] or [Both] is selected.
To set Surface Flat
In the Light 1 menu (4156.3), press [Surface Flat], turning
it on.
When [Non Linear] is selected in the <Surface Select>
group of the Spot Lighting menu (4156), only the part of
the surface being illuminated by light from the currently
set light source has the state as if [Flat] had been selected.
To set the shape of the lighting
1 In the Light 1 menu (4156.3), press [Shape], turning it
on.
2 Set the following parameters.
No. Parameter Adjustment
1Total
Ambient
Brightness of whole image
2 Intensity Intensity (brightness) of the light
source
3 Soft Softness of the illuminated area
No. Parameter Adjustment
1 Longitude Longitude
a)
2 Latitude Latitude
No. Parameter Adjustment
1 X Movement in X-axis direction
b)
2 Y Movement in Y-axis direction
c)
3 Z Movement in Z-axis direction
d)
No. Parameter Adjustment
1 X Movement in X-axis direction
b)
2 Y Movement in Y-axis direction
c)
3 Z Movement in Z-axis direction
d)
4 Longitude Longitude
a)
No. Parameter Adjustment
5 Amp Light separation distance
a)
Notes
No. Parameter Adjustment
1 Shape Ptn Shape pattern
a)
