25
a) Button name when setting in the Setup menu. When the display differs
from that on the cross-point pad, the button name shown in parentheses
( ) is displayed.
b) Disabled in key/AUX bus delegation mode.
c) 1st row is disabled in key/AUX bus delegation mode.
d) Enabled in key/AUX bus delegation mode only.
Key/AUX bus delegation mode
Setting key/AUX bus delegation mode in the Setup menu
allows you to use the 1st row buttons as 2nd row
delegation buttons.
For details, see “Setting the Cross-Point Control Block to
Key/AUX Bus Delegation Mode” (page 395).
You can assign the following bus/function delegation
buttons to the 1st row.
KEY1 to KEY8
1)
, UTIL1, UTIL2, DME EXT, DME
UTIL1, DME UTIL2, EDIT PVW, AUX1 to AUX48,
FMS1, FMS2, DME1 V to DME4 V
2)
, DME1 K to DME4
K
2)
, CCR1, CCR2, UTIL/SBOX1 to UTIL/SBOX10
POST MACRO Sets macro attachment in post
macro mode.
MACRO ATTACH
ENABLE
Enables macro attachments
assigned to buttons of the M/E
banks and PGM/PST bank.
DISP MODE1 to DISP
MODE6
(XXX)
Selects display mode 1 to 6 (display
mode button).
XXX = display mode name (up to
12 characters)
ROW-n KEY1 to ROW-
n KEY8
b)
(KEY1 to KEY8)
Assigns key 1 to 8 buses to the 1st
row or 2nd row.
n = 1 or 2
ROW-n UTIL1
b)
ROW-n UTIL2
b)
(UTL1, UTL2)
Assigns utility 1 and 2 buses to the
1st row or 2nd row.
n = 1 or 2
ROW-n DME EXT
b)
(DME EXT)
Assigns DME external video bus to
the 1st row or 2nd row.
n = 1 or 2
ROW-n DME UTIL1
b)
ROW-n DME UTIL2
b)
(DME UTL1, DME
UTL2)
Assigns DME utility 1 and 2 buses
to the 1st row or 2nd row.
n = 1 or 2
ROW-n UTIL/SBOX1
to ROW-n UTIL/
SBOX10
b)
(UTL/SB 1 to UTL/
SB10)
Assigns utility/shotbox bank 1 to 10
to the 1st row or 2nd row.
n = 1 or 2
Xpt Hold Status
(XPTHLD: AB U12
K1234 K5678)
Displays buses for which cross-
point hold is set.
XPTHLD BKGD A
XPTHLD BKGD B
Sets cross-point hold for the
background A or B bus.
XPTHLD KEY1 to
XPTHLD KEY8
Sets cross-point hold key 1 to 8
buses.
XPTHLD UTIL1
XPTHLD UTIL2
(XPTHLD UTL1,
XPTHLD UTL2)
Sets cross-point hold for the utility 1
and 2 buses.
XPTHLD DME EXT Sets cross-point hold for the DME
external video bus.
XPTHLD DME UTIL1
XPTHLD DME UTIL2
(XPTHLD DME UTL1,
XPTHLD DME UTL2)
Sets cross-point hold for the DME
utility 1 and 2 buses.
ROW-n XPTHLD
c)
(XPT HOLD)
Sets cross-point hold for the buses
assigned to the 1st row to 4th row.
n = 1 to 4
ROW-n P/P OUT1
c)
ROW-n M/E-1 OUT1 to
ROW-n M/E-5 OUT1
c)
(XXX)
Loads images (OUT1) from the
PGM/PST and M/E-1 to M/E-5
banks into the 1st row to 4th row
(re-entry buttons).
n = 1 to 4
XXX = Name set to P/P OUT1, M/
E-1 OUT1 to M/E-5 OUT1
Button name
a)
Description
ROW-n P/P OUT6
c)
ROW-n M/E-1 OUT6 to
ROW-n M/E-5 OUT6
c)
(XXX)
Loads images (OUT6) from the
PGM/PST and M/E-1 to M/E-5
banks into the 1st row to 4th row
(re-entry buttons).
n = 1 to 4
XXX = Name set to P/P OUT6, M/
E-1 OUT6 to M/E-5 OUT6
UTIL
b)
Assigns the specified bus to the 1st
row to 4th row in utility bus mode.
SHIFT ALL
c)
Switches the cross-point button
rows on all buses to the shifted
state.
XPTPAD COPY Copies the cross-point pad settings.
AUX MIX
d)
Executes an AUX mix transition
when the AUX bus is selected.
KEY
d)
Selects the signal on the key side in
the 2nd row.
XPT INHBT SET Sets/releases inhibit mode for
cross-point buttons.
XPT INHBT ALLCLR Releases inhibit mode for all cross-
point buttons.
DUAL BKGD BUS Toggles dual background bus
mode.
ROW-n PROT
c)
Inhibits button operation on the 1st
row to 4th row.
n = 1 to 4
MACRO TAKE
(TAKE)
Executes a macro take operation.
Macro Status
(EVENT XX/XX)
Displays the macro status.
XX/XX = executed event number /
total number of events
MACRO:XXX
(XXX)
Recalls a macro register (1 to 250).
XXX = macro register name (up to
8 characters)
Button name
a)
Description
