Sony XVS Series

468
StartTc Device? 1 to 12, FrameMemory1Clip to
FrameMemory20Clip
Target device
MasterSnapshot Register? 1 to 99 Target register number
MasterTimelineRecall Register? 1 to 99 Target register number
RouterXpt DestinationButton? 1 to 128 Router cross-point button
Source? 1 to 1024 Router source number
Level? 1 to 8 Router level selection
PatternLimit ME? ME1 to ME5, PP Target control block
Status? ToOn (a),
ToOff (b),
Any (c)
Pattern limit status
(a): Pattern limit applies
(b): Pattern limit does not apply
(c): The pattern limit status always changes
TransitionType ME? ME1 to ME5, PP Target control block
TransitionType? Mix, NAM, SuperMix,
PresetColorMix, Wipe,
DMEWipe,
FM1&2Clip, FM3&4Clip,
FM5&6Clip, FM7&8Clip
Transition type
KeyTransitionType ME? ME1 to ME5, PP Target control block
Key? Key1 to Key8 Key of the target independent key transition
Direction? On (a),
Off (b),
Any (c)
Independent key transition execution mode
(a): Key is inserted
(b): Key is removed
(c): Transition is always executed
KeyTransitionType? Mix, Wipe, DMEWipe, Cut Transition type of the independent key transition
NextTransition ME? ME1 to ME5, PP Target control block
All? On, Off Target next transition
KeyPriority? On, Off Target next transition
BKGD? On, Off Target next transition
Key1? to Key8? On, Off Target next transition
FadeToBlack Time? Current (a),
0 to 999
Transition rate (number of frames)
(a): Mode in which the current value set for fade
to black is used
TimelineDirectionNormal Region? ME1 to ME5, PP, User1 to
User8, DME1 to DME4, PBus,
Device1 to Device12, GPI,
Current (a)
Target region
(a): Mode in which operation takes place in the
region currently specified in the numeric keypad
control block
TimelineDirectionReverse Region? ME1 to ME5, PP, User1 to
User8, DME1 to DME4, PBus,
Device1 to Device12, GPI,
Current (a)
Target region
(a): Mode in which operation takes place in the
region currently specified in the numeric keypad
control block
TimelineNormalReverseOn Region? ME1 to ME5, PP, User1 to
User8, DME1 to DME4, PBus,
Device1 to Device12, GPI,
Current (a)
Target region
(a): Mode in which operation takes place in the
region currently specified in the numeric keypad
control block
TimelineNormalReverseOff Region? ME1 to ME5, PP, User1 to
User8, DME1 to DME4, PBus,
Device1 to Device12, GPI,
Current (a)
Target region
(a): Mode in which operation takes place in the
region currently specified in the numeric keypad
control block
Symbol Parameter name Arguments Description
