Figure 54 - Flow Meter Removal
5.2.2 Flow Meter Removal
For information on the Electronic Flowmeter (EFM) option, please
see Chapter 6 in this manual.
To remove the Flow Meter Assembly:
1. Remove front cover (see section 5.1).
2. Remove the two M4 screws each side of the fl ow meter while supporting
the fl ow meter.
Detailed Repair Procedures
