Spacelabs BleaseSirius - Compensation

36
To calculate the increase in TV:
The 735ml is the actual ventilator output into the breathing circuit to give
500ml at the catheter mount. The value must be recalculated every time volume
controlled ventilation starts.
2.2.3 Compensation
Mode Compliance Fresh Gas
Volume Control
P P
Pressure Support
O P
SIMV-VC + PSV
P P
SIMV-PC + PSV
O P
Pressure Control
O P
C
t
= = 25
20cmH
2
O
500mL
new TV = 500 * (
1 + ) = 735mL
25 8
8
-
