Spacelabs BleaseSirius - 1.3 Pneumatics

25
1.3 Pneumatics
1.3.1 Gas-Specifi c Color Specifi cations
Gas ISO ANSI
Oxygen White Green
Nitrous Oxide Blue Blue
MED AIR Black Yellow
1.3.2 Gas Supply Combinations
Max No. of Gases 3
Max No. of Cylinders 4
Max No. of Pipelines 3
Max No. of Gauges 7
Max Cylinder Size
(using PIV Index)
E
Large Cylinder Kit Max. 2
1.3.3 Common Gas Outlet
The common gas outlet is fi tted onto the front of the machine below the work
surface. It will accept a 22mm female or a 15mm male taper coupling.
Technical Description
