5.19.12 Exchanging of Fuses (EF533789)
WARNING: The use of incorrectly rated fuses constitutes a
fi re hazard. Replace the two fuses only with the
correct type and rating of fuse.
The combined IEC socket/fuse holder is located underneath the ventilator,
below the fl owblock.
1. Locate the two small tabs.
2. Pull these tabs toward you using your
fi nger and thumb.
3. The fuses are now visible and can be
replaced.
4. After replacing the fuses, push the
compartment back into the outlet.
5. If a fuse fails a second time, contact a
Spacelabs technical engineer.
Detailed Repair Procedures
Figure 145 - Replace the Fuses
