5.16 Braking System Maintenance.
1. Remove the 2 pedal
screws.
2. Slide the pedal out.
Figure 126 - Pedal Screw Location
Figure 127 - Hex Bar
Figure 128 - Hex Bar Removal
3. Slide the hexagonal bar out.
