4. Refi t the outer part of the connector and tighten the two small grub
screws.
5. Repeat for all three pipelines.
6. Note each gas type has a unique fi tting and can not be incorrectly
mixed.
7. Refi t the pipeline and check for leaks.
Figure 9 - Pipeline Fitting & ‘O’ Ring
