1.1 Description
1.1.1 General
The BleaseSirius anesthetic machines contain all the pneumatic circuitry,
controls, monitoring, ancillaries and storage required to control, distribute and
mix medical gases and anesthetic agents in order to deliver them to a patient
system.
The BleaseSirius anesthetic machine is based on the Frontline machines. The
BleaseSirius has enhanced components and new features and improvements.
The BleaseSirius anesthetic machine is designed to comply with the following:
ASTM F-1850, UL 60601-1, ISO 5358, IEC 60601-1, IEC 60601-2-13, BS EN
740 and other International Standards.
The BleaseSirius machine consists of the major components described below
(See Figure 1).
1.1.2 The Frame
The frame is made of steel supported on a cast aluminum base with four castors,
there is a brake pedal at the bottom of the trolley. The steel frame is covered by
moldings with a painted fi nish.
1.1.3 Pneumatic Assembly
The frame contains the pneumatic assembly. The pneumatic unit contains the
gas supply inputs, the pneumatics that regulate the supply pressures to a usable
pressure, the oxygen failure alarm and its logic circuitry, the common gas outlet,
the user controls and the pneumatic power outlets. Above the work surface are
the cylinder contents and pipeline pressure gauges, fl ow control valves, hypoxic
guard and fl owblock assemblies, the vaporizer back bar and the uprights which
support the monitor shelf.
1.1.4 The Monitor Shelf
The monitor shelf A in Figure 1, is mounted on top of the machine. Loading
should not exceed 25Kg/55.1lbs.
In US markets, use a cord fi tted with a NEMA 5-15 hospital grade plug to connect
the BleaseSirius to the mains supply. Connection of equipment to the auxiliary
mains socket outlets may increase leakage currents to values exceeding the
allowable limits.
Technical Description
