155
5.13 Internal Absorber
1. To release the lower molding, remove the twelve M5 screws.
Photos show the absorber with bypass switch. Some models
do not have the bypass switch.
Figure 114 - Absorber Molding 01
Figure 115 - Absorber Molding 02
Detailed Repair Procedures
