5.19.3 Removal of Inspiratory Block (FR137025)
1. Disconnect the electrical
connectors and gas supply
as shown.
2. Remove the connector
from inspiratory valve as
shown.
3. On the rear of the
ventilator, remove the four
screws as shown, then
remove the cover.
Detailed Repair Procedures
