Spacelabs BleaseSirius - Figure 77 - Assemble the Spring, Spring Rest and Bonnet; Figure 78 - Slip Ring Location; Figure 79 - Diaphragm Assembly

126
8. Place the upper spring rest and the spring into the bonnet as shown in
Figure 77.
Figure 77 - Assemble the Spring, Spring Rest and Bonnet
9. Place the slip ring into the bonnet, as
shown in Figure 78.
10. Place the diaphragm assembly onto
the spring, as shown in Figure 79.
Figure 79 - Diaphragm Assembly
Figure 78 - Slip Ring Location
Detailed Repair Procedures
