Using the PRAAA Password
Prepare the device.
1. Set up a patient circuit and test lung with a fl ow measuring device
attached to the inspiratory port of the patient circuit.
2. Perform the pre use leak and compliance checks.
3. Enter SETUP > CONFIGURATION > SERVICE MODE. Enter the
password, PRAAA. The following screen will be displayed.
Detailed Repair Procedures
4. Run the ventilator in volume control with the sensor at the patient using
the following settings:
BPM 12
Volume 500 ml
I:E 1:2.0
Pressure Limit 50
PEEP OFF
5. Once the volume has stabilized, verify that the measured volume on the
fl ow analyzer attached to the inspiratory port is 450 - 550 ml. The Vte and
Vti readings on the ventilator (displayed in the red box) should represent
the measured delivered volume +/- 5ml. If an adjustment is necessary,
the gain factor can be adjusted for both Vte and Vti to align the ventilators
displayed measured volume with the actual measured delivered volume.
