219
12. Reconnect the four fl ow tubes to the EFM.
13. Reconnect the light pipe to the EFM circuit board.
14. Connect the ribbon cable and the power connector to the EFM.
15. Replace the EFM on the machine and secure it with the four retaining
screws [two one each side].
16. Using the Service Application, confi gure the fl ow tubes.
EFM Option
