ST STM32F101 series Reference Manual

Low-, medium-, high- and XL-density reset and clock control (RCC) RM0008
111/1128 DocID13902 Rev 15
7.3.6 AHB peripheral clock enable register (RCC_AHBENR)
Address offset: 0x14
Reset value: 0x0000 0014
Access: no wait state, word, half-word and byte access
Note: When the peripheral clock is not active, the peripheral register values may not be readable
by software and the returned value is always 0x0.
Bit 5 TIM7RST: TIM7 timer reset
Set and cleared by software.
0: No effect
1: Reset TIM7
Bit 4 TIM6RST: TIM6 timer reset
Set and cleared by software.
0: No effect
1: Reset TIM6
Bit 3 TIM5RST: TIM5 timer reset
Set and cleared by software.
0: No effect
1: Reset TIM5
Bit 2 TIM4RST: TIM4 timer reset
Set and cleared by software.
0: No effect
1: Reset TIM4
Bit 1 TIM3RST: TIM3 timer reset
Set and cleared by software.
0: No effect
1: Reset TIM3
Bit 0 TIM2RST: TIM2 timer reset
Set and cleared by software.
0: No effect
1: Reset TIM2
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved
SDIO
EN
Res.
FSMC
EN
Res.
CRCE
N
Res.
FLITF
EN
Res.
SRAM
EN
DMA2
EN
DMA1
EN
rw rw rw rw rw rw rw
Bits 31:11 Reserved, must be kept at reset value.
Bit 10 SDIOEN: SDIO clock enable
Set and cleared by software.
0: SDIO clock disabled
1: SDIO clock enabled
Bits 9 Reserved, always read as 0.
