Window watchdog (WWDG) RM0008

497/1128 DocID13902 Rev 15

20.6.4 WWDG register map

The following table gives the WWDG register map and reset values.

Refer to Table 3 on page 51 for the register boundary addresses.

Table 99. WWDG register map and reset values

Offset Register

0x00

WWDG_CR

Reserved

WDGA

T[6:0]

Reset value 01111111

0x04

WWDG_CFR

Reserved

EWI

WDGTB1

WDGTB0

W[6:0]

Reset value 0001111111

0x08

WWDG_SR

Reserved

EWIF

Reset value 0
