DocID13902 Rev 15 484/1128

RM0008 Real-time clock (RTC)

484

18.4.7 RTC register map

RTC registers are mapped as 16-bit addressable registers as described in the table below:

Refer to Table 3 on page 51for the register boundary addresses.

Table 95.

RTC register map and reset values

Offset Register

0x00

RTC_CRH

Reserved

OWIE

ALRIE

SECIE

Reset value 000

0x04

RTC_CRL

Reserved

RTOFF

CNF

RSF

OWF

ALRF

SECF

Reset value 100000

0x08

RTC_PRLH

Reserved

PRL[19:16]

Reset value

0000

0x0C

RTC_PRLL

Reserved

PRL[15:0]

Reset value

1000000000000000

0x10

RTC_DIVH

Reserved

DIV[31:16]

Reset value

0000000000000000

0x14

RTC_DIVL

Reserved

DIV[15:0]

Reset value

1000000000000000

0x18 RTC_CNTH

Reserved

CNT[13:16]

Reset value

0000000000000000

0x1C

RTC_CNTL

Reserved

CNT[15:0]

Reset value

0000000000000000

0x20

RTC_ALRH

Reserved

ALR[31:16]

Reset value

1111111111111111

0x24

RTC_ALRL

Reserved

ALR[15:0]

Reset value

1111111111111111
