Analog-to-digital converter (ADC) RM0008
239/1128 DocID13902 Rev 15
11.12.3 ADC control register 2 (ADC_CR2)
Address offset: 0x08
Reset value: 0x0000 0000
Bit 6 AWDIE: Analog watchdog interrupt enable
This bit is set and cleared by software to enable/disable the analog watchdog interrupt.
0: Analog watchdog interrupt disabled
1: Analog watchdog interrupt enabled
Bit 5 EOCIE: Interrupt enable for EOC
This bit is set and cleared by software to enable/disable the End of Conversion interrupt.
0: EOC interrupt disabled
1: EOC interrupt enabled. An interrupt is generated when the EOC bit is set.
Bits 4:0 AWDCH[4:0]: Analog watchdog channel select bits
These bits are set and cleared by software. They select the input channel to be guarded by
the Analog watchdog.
00000: ADC analog Channel0
00001: ADC analog Channel1
....
01111: ADC analog Channel15
10000: ADC analog Channel16
10001: ADC analog Channel17
Other values reserved.
Note: ADC1 analog Channel16 and Channel17 are internally connected to the temperature
sensor and to V
REFINT
, respectively.
ADC2 analog inputs Channel16 and Channel17 are internally connected to V
SS
.
ADC3 analog inputs Channel9, Channel14, Channel15, Channel16 and Channel17 are
connected to V
SS
.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
TSVRE
FE
SWSTA
RT
JSWST
ART
EXTTR
IG
EXTSEL[2:0] Res.
rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
JEXTT
RIG
JEXTSEL[2:0] ALIGN Reserved DMA
Reserved
RST
CAL
CAL CONT ADON
rw rw rw rw rw Res. rw rw rw rw rw
