Power control (PWR) RM0008

71/1128 DocID13902 Rev 15

PVD output interrupt can be generated when V

DDA

drops below the PVD threshold

and/or when V

DDA

rises above the PVD threshold depending on EXTI line16

rising/falling edge configuration. As an example the service routine could perform

emergency shutdown tasks.

Figure 6. PVD thresholds

DDA

PVD output

100 mV

hysteresis

PVD threshold

Default Chapter2
