General-purpose and alternate-function I/Os (GPIOs and AFIOs) RM0008
187/1128 DocID13902 Rev 15
Memory map and bit definitions for connectivity line devices:
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res.
PTP_P
PS_RE
MAP
TIM2IT
R1_
IREMA
P
SPI3_
REMA
P
Res.
SWJ_
CFG[2:0]
MII_R
MII_SE
L
CAN2_
REMA
P
ETH_R
EMAP
Reserved
TIM5C
H4_IRE
MAP
rw rw rw w w w rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PD01_
REMA
P
CAN1_REMAP
[1:0]
TIM4_
REMA
P
TIM3_REMAP
[1:0]
TIM2_REMAP
[1:0]
TIM1_REMAP
[1:0]
USART3_
REMAP[1:0]
USART2
_
REMAP
USART1
_
REMAP
I2C1_
REMA
P
SPI1_
REMA
P
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bit 31 Reserved, must be kept at reset value.
Bit 30 PTP_PPS_REMAP: Ethernet PTP PPS remapping
This bit is set and cleared by software. It enables the Ethernet MAC PPS_PTS to be output
on the PB5 pin.
0: PTP_PPS not output on PB5 pin.
1: PTP_PPS is output on PB5 pin.
Note: This bit is available only in connectivity line devices and is reserved otherwise.
Bit 29 TIM2ITR1_IREMAP: TIM2 internal trigger 1 remapping
This bit is set and cleared by software. It controls the TIM2_ITR1 internal mapping.
0: Connect TIM2_ITR1 internally to the Ethernet PTP output for calibration purposes.
1: Connect USB OTG SOF (Start of Frame) output to TIM2_ITR1 for calibration purposes.
Note: This bit is available only in connectivity line devices and is reserved otherwise.
Bit 28 SPI3_REMAP: SPI3/I2S3 remapping
This bit is set and cleared by software. It controls the mapping of SPI3_NSS/I2S3_WS,
SPI3_SCK/I2S3_CK, SPI3_MISO, SPI3_MOSI/I2S3_SD alternate functions on the GPIO
ports.
0: No remap (SPI_NSS-I2S3_WS/PA15, SPI3_SCK-I2S3_CK/PB3, SPI3_MISO/PB4,
SPI3_MOSI-I2S3_SD/PB5)
1: Remap (SPI3_NSS-I2S3_WS/PA4, SPI3_SCK-I2S3_CK/PC10, SPI3_MISO/PC11,
SPI3_MOSI-I2S3_SD/PC12)
Note: This bit is available only in connectivity line devices and is reserved otherwise.
Bit 27 Reserved
Bits 26:24 SWJ_CFG[2:0]: Serial wire JTAG configuration
These bits are write-only (when read, the value is undefined). They are used to configure the
SWJ and trace alternate function I/Os. The SWJ (Serial Wire JTAG) supports JTAG or SWD
access to the Cortex
®
debug port. The default state after reset is SWJ ON without trace.
This allows JTAG or SW mode to be enabled by sending a specific sequence on the JTMS /
JTCK pin.
000: Full SWJ (JTAG-DP + SW-DP): Reset State
001: Full SWJ (JTAG-DP + SW-DP) but without NJTRST
010: JTAG-DP Disabled and SW-DP Enabled
100: JTAG-DP Disabled and SW-DP Disabled
Other combinations: no effect
