9D-1 Exterior Parts:
Body and Acc essories
Exterior Parts
Schematic and Routing Diagram
Seat Lock Cable Routing Diagram
B944H19402001
1. Seat lock cable 2. Seat lock
1
1
2
I944H1940021-01

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki SFV650 and is the answer not in the manual?

Suzuki SFV650 Specifications

General IconGeneral
ManufacturerSuzuki
ModelSFV650
CategoryNaked
Bore x Stroke81.0 mm x 62.6 mm
Compression Ratio11.5:1
Fuel SystemFuel Injection
IgnitionElectronic ignition (transistorized)
LubricationWet sump
StarterElectric
Transmission6-speed, constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front BrakesDisc, twin
Rear BrakesDisc
Front Tire Size120/70ZR17M/C (58W), tubeless
Rear Tire Size160/60ZR17M/C (69W), tubeless
Ground Clearance135 mm (5.3 in)
Curb Weight202 kg (445 lbs)
Overall Width760 mm
Wheelbase1445 mm (56.9 in)
Fuel Capacity14.5 L
Engine Type4-stroke, liquid-cooled, DOHC, 90-degree V-twin
Overall Length2, 130 mm (83.9 in)
Overall Height1090 mm
