TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 2-3. Terminal Functions (continued)
SIGNAL
TYPE
(1)
IPD/IPU
(2)
DESCRIPTION
NAME NO.
MULTICHANNEL BUFFERED SERIAL PORT 1 AND MULTICHANNEL BUFFERED SERIAL PORT 0 (McBSP1 and McBSP0)
McBSP external clock source (as opposed to internal) (I)
CLKS AJ4 I IPD
[shared by McBSP1 and McBSP0]
MULTICHANNEL BUFFERED SERIAL PORT 1 (McBSP1)
CLKR1/GP[0] AF4 I/O/Z IPD McBSP1 receive clock (I/O/Z) or GP[0] (I/O/Z) [default]
FSR1/GP[10] AE5 I/O/Z IPD McBSP1 receive frame sync (I/O/Z) or GP[10] (I/O/Z) [default]
DR1/GP[8] AH5 I/O/Z IPD McBSP1 receive data (I) or GP[8] (I/O/Z) [default]
DX1/GP[9] AG5 I/O/Z IPD McBSP1 transmit data (O/Z) or GP[9] (I/O/Z) [default]
FSX1/GP[11] AG4 I/O/Z IPD McBSP1 transmit frame sync (I/O/Z) or GP[11] (I/O/Z) [default]
CLKX1/GP[3] AF5 I/O/Z IPD McBSP1 transmit clock (I/O/Z) or GP[3] (I/O/Z) [default]
MULTICHANNEL BUFFERED SERIAL PORT 0 (McBSP0)
CLKR0 AG1 I/O/Z IPU McBSP0 receive clock (I/O/Z)
FSR0 AH3 I/O/Z IPD McBSP0 receive frame sync (I/O/Z)
DR0 AJ5 I IPD McBSP0 receive data (I)
DX0 AF6 I/O/Z IPD McBSP0 transmit data (O/Z)
FSX0 AJ3 I/O/Z IPD McBSP0 transmit frame sync (I/O/Z)
CLKX0 AG6 I/O/Z IPU McBSP0 transmit clock (I/O/Z)
UNIVERSAL TEST AND OPERATIONS PHY INTERFACE for ASYNCHRONOUS TRANSFER MODE (ATM) [UTOPIA SLAVE]
UTOPIA SLAVE (ATM CONTROLLER) - TRANSMIT INTERFACE
Source clock for UTOPIA transmit driven by Master ATM Controller.
When the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this
UXCLK/MTCLK/
N4 I/O/Z pin is either EMAC MII transmit clock (MTCLK) or the EMAC RMII reference
RMREFCLK
clock. The EMAC function is controlled by the MACSEL[1:0] (AEA[10:9] pins).
For more detailed information, see Section 3, Device Configuration.
Transmit cell available status output signal from UTOPIA Slave.
0 indicates a complete cell is NOT available for transmit
UXCLAV/GMTCLK K5 I/O/Z 1 indicates a complete cell is available for transmit
When the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this
pin is EMAC GMII transmit clock. MACSEL[1:0] dependent.
UTOPIA transmit interface enable input signal. Asserted by the Master ATM
Controller to indicate that the UTOPIA Slave should put out on the Transmit
Data Bus the first byte of valid data and the UXSOC signal in the next clock
UXENB/MTXEN/
J5 I/O/Z cycle.
RMTXEN
When the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this
pin is either the EMAC MII transmit enable [default] or EMAC RMII transmit
enable or EMAC GMII transmit enable. MACSEL[1:0] dependent.
Transmit Start-of-Cell signal. This signal is output by the UTOPIA Slave on the
rising edge of the UXCLK, indicating that the first valid byte of the cell is
available on the 8-bit Transmit Data Bus (UXDATA[7:0]).
UXSOC/MCOL K3 I/O/Z
When the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this
pin is either the EMAC MII collision sense or EMAC GMII collision sense.
MACSEL[1:0] dependent.
UXADDR4/MDCLK M5 I UTOPIA transmit address pins (UXADDR[4:0]) (I)
As UTOPIA transmit address pins, UTOPIA_EN (AEA12 pin) = 1:
UXADDR3/MDIO N3 I
• 5-bit Slave transmit address input pins driven by the Master ATM Controller
UXADDR2/PCBE3 P5 I
to identify and select one of the Slave devices (up to 31 possible) in the
ATM System.
UXADDR1/PIDSEL R3 I
When the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0) and if
the PCI_EN pin = 1, these pins are PCI peripheral pins:
UXADDR0/PTRDY P4 I
PCI command/byte enable 3(PCBE3) [I/O/Z],
PCI initialization device select (PIDSEL) [I], and
PCI target ready (PTRDY) [I/O/Z].
36 Device Overview Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
