Removing and Installing the Hydraulic Filter Access
Cover
Figure 82
G446042
Mounting bolt
Hydraulic filter access cover
1. Park the machine on a level surface, lower any attachments to the ground,
engage the parking brake, and remove the key from the ignition.
2. Switch the main circuit breaker to the O
FF position, to de-energize the electrical
system.
3. Remove the hydraulic filter access cover
, by removing the mounting bolts .
4. To install the hydraulic filter access cover, position the cover on the machine
aligning the mounting holes.
5. Install the mounting bolts.
6. Switch the main circuit breaker to the O
N position, to energize the electrical
system.
4520P Page 7–17 Chassis: Service and Repairs
09.40003Rev 00
