Changing Rear Transaxle Fluid (continued)
2. Park the machine on a level surface, engage the parking brake, and remove the
key from the ignition.
3. Locate and remove the drain plug
on the bottom of the transaxle.
4. Drain the fluid into an approved container.
5. Replace the o-ring and install the drain plug 37 Nm (27 ft-lb).
6. Locate and remove the fill plug
on the back of the transaxle.
7. Fill the rear transaxle with oil to the bottom of the oil fill hole.
8. Replace the o-ring and install the fill plug 37 Nm (27 ft-lb).
