Adjusting the Hydraulic Pump Tow Valve (continued)
CAUTION
Over tightening the tow valve will cause damage to the valve seat.
6. Tighten the valve, torque the valve to 12 Nm (9 ft-lb).
7. After the valve is tightened, install the hydraulic pump cover.
8. Check the forward and reverse movement of the machine.
Hydraulic System: General Information Page 5–8 4520P
09.40003Rev 00
