Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-5
Main Assembly Parts List 9.1
No. Part number Qty Part Name and (part description)
0 N/S Set_Xerox
1 108R00594 1 Transfer Belt
2 108R00593 1 Imaging Unit
3 106R00679
106R00684
1
1
Standard Capacity Black Toner Cartridge
High Capacity Black Toner Cartridge
4 106R00676
106R00680
1
1
Standard Capacity Cyan Toner Cartridge
High Capacity Cyan Toner Cartridge
5 106R00677
106R00681
1
1
Standard Capacity MagentaToner Cartridge
High Capacity Black Magenta Cartridge
6 106R00678
106R00682
1
1
Standard Capacity Yellow Toner Cartridge
High Capacity Yellow Toner Cartridge
7 116-1850-00 1 Main Drive ASM
8 116-1851-00 1 DEVE Drive ASM
9 116-1579-00
116-1567-00
1
1
Fuser 230V (Customer Replaceable Spare)
Fuser 110V (Customer Replaceable Spare)
10 116-1852-00 1 Main Controller Board
11 1 Main Frame
12 116-1853-00 1 Exit ASM
13 116-1928-00 1 Duplex ASM
14 116-1854-00 1 Paper Tray, Tray 1 (FCT)
15 1Front Cover
16 116-1855-00 1 Rear Cover ASM
16-1 1 Cover Rear
16-2 1 Cover Rear Deco
16-3 1 Cover Open Board
16-4 1 Label (P)-Rear
16-S8 1Screw
17 116-1856-00 1 Top Cover ASM
18 116-1857-00 1 DEVE Cover ASM
19 116-1859-00
116-1858-00
1
1
LVPS (SMPS) ASM, 230 V
LVPS (SMPS) ASM, 110 V
19-1 1
1
LVPS (SMPS) V2-220V
LVPS (SMPS) V1-110V
19-2 1 Bracket LVPS (SMPS)
19-3 1 Shield - LVPS (SMPS)
19-S9 1 Screw-Taptite
20 116-1860-00 1 HVPS
21 116-1861-00 1 Laser Unit (LSU)
22 2 Plain Washer
23 P/O hardware kit 2 E-ring
24
116-1915-00 1 Sheet ECU Board (Main Board Shield)
25 1 Ground Harness LIU
26 1 ICT-PIN ADF
27 116-1863-00 1 Fuser Fan
28 116-1929-00 1 CBF Harness-Main Laser (LSU)
29 116-1930-00 1 CBF Harness-Main Panel (Control Panel)
30 116-1931-00 1 CBF Harness-DEVE Motor
31 116-1932-00 1 CBF Harness-Main Motor

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
