Xerox Phaser 6100 Service Manual

Parts List
9-6
32 116-1933-00 1 Harness-Main LVPS (SMPS)
33 116-1934-00 1 Clutch Cam Solenoid
34 1 Bushing 8/5
35 116-1864-00 1 Sheet Cover Front OPE (Control Panel Cover)
36 1 HVPS Shield
37 1 LVPS (SMPS) Cover
38 1 OPC Drive Gear 2_Z40
39 1 Cam-T2 Engage
40 2 Shaft Cover Exit Hinge
41 1 Bracket Guide
42 1 Bracket Upper
43 1 Bracket Lower
43-1 1 Bracket Bracket Upper
43-2 1 Bracket Option
43-S9 2Screw
44 119-6506-00 1 500-Sheet Feeder (SCF)
45 1 Cover Sensor Base
46 1 Harness C
47 116-1936-00 1 Harness D
48 1 Cable Clamp
49 116-1868-00 1 Laser (LSU) Cleaner ASM
49-1 1 Shutter Laser Cleaner
49-2 1 Shaft Laser Cleaner
49-3 1 E-Ring Laser Cleaner
49-4 1 Plate-Link Rear
49-5 1 Plate-Link Front
50 1 DEVE Open Link
51 1 DEVE Open Link Guide
52 116-1865-00 1 Cover-LSU (Laser Cover)
53 116-1885-00 1 Terminals
54 116-1566-00 1 Transfer Roller (T2) (Customer Replaceable
Spare)
55 1 Bracket LVPS (SMPS) Cover
56 1 Fuser Unit Duct
56-1 1 Fuser Duct Lower
56-2 1 Fuser Duct Upper
56-S8 1 Screw-Taptite
57 1 Waste Toner Cartridge
57-1 1 Waste Toner Cover Upper
57-2 1 Waste Toner Cover Lower
57-3 2 Toner Cap OPC
58 116-1910-00 1 Main Drive Hardware Kit
S2 P/O Screw Kit 2 Screw-Tapping
S5 P/O Screw Kit 6 Screw-Taptite
S8 P/O Screw Kit 50 Screw-Taptite
S9 P/O Screw Kit 21 Screw-Taptite
S14 P/O Screw Kit 11 Screw-Taptite
S15 P/O Screw Kit 2 Screw-Machine
No. Part number Qty Part Name and (part description)

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
