Xerox Phaser 6100 Service Manual

Parts List
Service Manual 9-13
Duplex Assembly 9.6
No. Part number Qty Part Name and (part description)
0 116-1928-00 1 Duplex ASM
1 1 Cover Right
1-1 1 Cover Duplex
1-2 1 Cover Dup Lock Shaft
1-3 1 Cover Duplex Handle
1-4 1Spring TS
1-5 1 Cover Dup Locker F
1-6 1 Cover Dup Locker R
1-7 1 Cover Duplex Link
1-8 1 Cover Duplex Link R
1-9 1 Cover Duplex Rail
1-10 1 Cover Duplex Rail R
1-11 2Spring EX
1-12 116-1877-00 1 MPT Tray ASM (Multi-Purpose Tray)
1-12-1 1 Tray Case MPT
1-12-2 2 Tray Link MPT
1-12-3 1 Guide Latch
1-12-4 1 Tray Cover MPT
1-12-5 1 Side Guide MPT
1-12-6 1 Tray Exit MPT
1-12-7 1 Label(R)Height MPT
2 116-1878-00 1 Duplex Unit
2-1 1 Bracket Guide A
2-2 1Holder Saw
2-3 1 Plate Saw
2-4 1 Frame Duplex
2-5 2 Pulley Belt
2-6 1 Belt Timing
2-7 2 Gear-Duplex Idler_Z25
2-8 1Cover Belt
2-9 1 Bracket Ground TR
2-10 2Spring ES
2-11 1 Gear-MPT/Dup Drive
2-12 1 Unit-T2_Assy
2-12-1 1E-Ring
2-12-2 1 Gear Transfer Idler Z47
2-12-3 1 Shaft Guide TR
2-12-4 2 Holder Transfer
2-12-5 1 Lever TR Front
2-12-6 1Lever TR Rear
2-12-7 1 Link TR Front
2-12-8 1 Link TR Rear
2-13 1 Bracket Ground TR1
2-14 2 Shaft Dup Driver
2-15 2 Rubber Exit RPR
2-16 2 Bushing TX(B4)
2-17 2Roller Exit

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
