Xerox Phaser 6100

Parts List
9-14
2-18 2 Fuser Exit Spring
2-19 1 Bracket Guide B
2-20 1 Bracket Guide Duplex
2-21 1 Bracket Ground B
2-22 1 Bracket Ground A
2-23 1 Bracket Ground D
2-24 1 Bracket Ground C
2-25 1 CBF-Harness Control Panel Ground (OPE)
2-26 1 Bushing Feed
2-27 1 Guide Lower Duplex
2-28 P/O Hardware Kit 1 Ring CS
2-29 1 Guide Feed
2-30 1 Poly Washer
S5 P/O Screw Kit 19 Screw-Taptite
S8 P/O Screw Kit 19 Screw-Taptite
No. Part number Qty Part Name and (part description)
