Xerox Phaser 6100

Connection Diagram
11-4
12a
Deve Drive(CN6) Solenoid(Deve 1st) C
Pin
Signal Name Dir Pin Signal Name
1
nSOL_DEV_1ST
<-
2
NC <-
3
AGND
<-
12b
Deve Drive(CN2) Solenoid(Deve 2nd) M
Pin
Signal Name Dir
Pin Signal Name
1
nSOL_DEV_2ND <-
2
NC <-
3 AGND
<-
12c
Deve Drive(CN7) Solenoid(Deve 3rd) Y
Pin Signal Name
Dir Pin
Signal Name
1
nSOL_DEV_3RD
<-
2
NC
<-
3 AGND
<-
12d
Deve Drive(CN3) Solenoid(Deve 4th) K
Pin
Signal Name
Dir
Pin
Signal Name
1
nSOL_DEV_4TH
<-
2
NC
<-
3
AGND
<-
13a
Deve Drive(CN8) Clutch(Deve 1st)
Pin Signal Name Dir Pin
Signal Name
1 nCLT_D EV_1ST <-
2 NC
<-
3 AGND
<-
13b
Deve Drive(CN4) Clutch(Deve 2nd)
Pin
Signal Name Dir
Pin
Signal Name
1 nCLT_DEV_2ND
<-
2
NC
<-
3
AGND
<-
13c
Deve Drive(CN9) Clutch(Deve 3rd)
Pin
Signal Name Dir
Pin Signal Name
1
nCLT_DEV_3RD
<-
2
NC
<-
3
AGND
<-
13d
Deve Drive(CN5) Clutch(Deve4th)
Pin
Signal Name
Dir
Pin
Signal Name
1
nCLT_DEV_4TH
<-
2
NC
<-
3
AGND
<-
14
Deve Drive(CN10) Solenoid(T1 clean)
Pin Signal Name Dir
Pin Signal Name
1
nSOL_T1_CLN <-
2
NC
<-
3 AGND
<-
15
Main BD(CN29) Fan Motor(Fuser)
Pin Signal Name
Dir
Pin Signal Name
1
nFAN_FUSER <-
2
NC <-
3
+24VF <-
16
Main BD(CN27) Main Motor
Pin
Signal Name
Dir
Pin
Signal Name
1
+24VF
1
+24V
2
+24VF
2
+24V
3 AGND
3
PGND
4
AGND 4
PGND
5
DGND
5
SGND
6
+5V
6
+5V
7
nBLDC_START1
7 START
8
nBLDC_RDY1
8
READY
9
BLDC_CLK1
9
CLOCK
10
DGND
10
CW/CCW
