Xerox Phaser 6100 - Page 207

Connection Diagram
Service Manual 11-5
17
Main BD(CN3
) Parallel Port
Pin
Signal Name Dir
Pin Signal Name
1
nSTB
<-
2
DATA0
<-
3
DATA1
<-
4
DATA2
<-
5
DATA3 <-
6
DATA4
<-
7
DATA5
<-
8 DATA6
<-
9
DATA7
<-
10
nACK
<-
11
BUSY
<-
12
PERROR
<-
13
SELECT
<-
14
nAUTOFD
<-
15
NC
<-
16
DGND
<-
17
AGND
<-
18
5V1
<-
Pin
Signal Name Dir
Pin
Signal Name
19
DGND
<-
20
DGND
<-
21
DGND
<-
22
DGND
<-
23 DGND
<-
24
DGND
<-
25
DGND
<-
26 DGND
<-
27
DGND <-
28 DGND
<-
29 DGND
<-
30
DGND
<-
31
nINIT
<-
32
nFAULT
<-
33
NC
<-
34
NC
<-
35
NC
<-
36
nSELECTIN
<-
18
Main BD(CN2) USB Port
Pin
Signal Name
Dir Pin
Signal Name
1 VBUS_2270
VBUS
2
DN
D- D+
3
DP
4
DGND
AGND
5
AGND
FGND
6
AGND
FGND
19
Main BD(CN4) Control Panel(CN2)
Pin
Signal Name
Dir
Pin
Signal Name
1
DGND
1
DGND
2
+5V
2
VCC
3
PANEL_TX
3
OPE_RXD
4
nRST_PANEL
4
/OPE_RST
5
PANEL_RX
5
OPE_TXD
