B.3 Parameter Table
394 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
■ U3: Fault History
■ U4: Maintenance Monitors
U2-11
(8AH)
Input Terminal Status at
Previous Fault
Displays the input terminal status at the previous fault. Displayed as in U1-10.
No signal output
available
––
U2-12
(8BH)
Output Terminal Status at
Previous Fault
Displays the output status at the previous fault. Displays the same status displayed in U1-11.
No signal output
available
––
U2-13
(8CH)
Drive Operation Status at
Previous Fault
Displays the operation status of the drive at the previous fault. Displays the same status
displayed in U1-12.
No signal output
available
––
U2-14
(8DH)
Cumulative Operation Time at
Previous Fault
Displays the cumulative operation time at the previous fault.
No signal output
available
1 h –
U2-15
(7E0H)
Soft Starter Speed Reference at
Previous Fault
Displays the speed reference for the soft starter at the previous fault.
This parameter is valid from the drive software version S3801 and later.
No signal output
available
0.01 Hz –
U2-16
(7E1H)
Motor q-Axis Current at
Previous Fault
Displays the q-axis current for the motor at the previous fault.
This parameter is valid from the drive software version S3801 and later.
Note: Available control modes for parameter U2-16 vary by drive model:
CIMR-E2A0004 to 2A0415 and 4A0002 to 4A0675: Available when A1-02 = 5
CIMR-E4A0930 and 4A1200: Available when A1-02 = 0,1
No signal output
available
0.10% –
U2-17
(7E2H)
Motor d-Axis Current at
Previous Fault
Displays the d-axis current for the motor at the previous fault.
This parameter is valid from the drive software version S3801 and later.
No signal output
available
0.10% –
U2-20
(8EH)
Heatsink Temperature at
Previous Fault
Displays the temperature of the heatsink when the most recent fault occurred.
No signal output
available
1°C–
U2-27
(7FAH)
Motor Temperature at Previous
Fault (NTC)
Displays the temperature of the motor when the most recent fault occurred.
Note: This parameter is available in models CIMR-E4A0930 and 4A1200.
No signal output
available
1°C–
U2-28
(7FCH)
M
alfunctioned Module
Disp
lay the module where the previous fault occurred at a decimal number.
Note: This parameter is available in models CIMR-E4A0930 and 4A1200.
No signal output
available
––
<19> This value's number of decimal places depends on the drive model. The value will have two decimal places (0.01 A) if the drive model is
CIMR-E2A0004 to 2A0040, 4A0002 to 4A0023 and one decimal place (0.1 A) if the drive model is CIMR-E2A0056 to 2A0415, 4A0031
to 4A1200.
<50> When reading the value of this monitor via MEMOBUS/Modbus a value of 8192 is equal to 100% of the drive rated output current.
No. (Addr.) Name Description
Analog Output
Level
Unit Page
U3-01 to
U3-04
(90H to 93H
(800H to
803H))
First to 4th Most Recent Fault
Displays the first to the fourth most recent faults.
No signal output
available
––
U3-05 to
U3-10
(804H to
809H)
5th to 10th Most Recent Fault
Displays the fifth to the tenth most recent faults.
After ten faults have occurred in the drive, data for the oldest fault is deleted. The most recent
fault appears in U3-01, with the next most recent fault appearing in U3-02. The data is moved to
the next monitor parameter every time a fault occurs.
No signal output
available
––
U3-11 to
U3-14
(94H to 97H
(80AH to
80DH))
Cumulative Operation Time at
1st to 4th Most Recent Fault
Displays the cumulative operation time when the first to the fourth most recent faults occurred.
No signal output
available
1 h –
U3-15 to
U3-20
(80EH to
813H)
Cumulative Operation Time at
5th to 10th Most Recent Fault
Displays the cumulative operation time when the fifth to the tenth most recent faults occurred.
No signal output
available
1 h –
No. (Addr.) Name Description
Analog Output
Level
Unit Page
U4-01
(4CH)
Cumulative Operation Time
Displays the cumulative operation time of the drive. The value for the cumulative operation
time counter can be reset in parameter o4-01. Use parameter o4-02 to determine if the operation
time should start as soon as the power is switched on or only while the Run command is present.
The maximum number displayed is 99999, after which the value is reset to 0.
No signal output
available
1 h –
No. (Addr.) Name Description
Analog Output
Level
Unit Page
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
SIEP_C710616_35.book 394 ページ ２０１５年１１月３０日 月曜日 午後２時２分
