B.3 Parameter Table
Parameter List
B
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 397
■ U6: Operation Status Monitors
■ U8: DriveWorksEZ Monitors
No. (Addr.) Name Description
Analog Output
Level
Unit Page
U6-01
(51H)
<18> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
Motor Secondary Current (Iq)
Displays the value of the motor secondary current (Iq). Motor rated secondary current is 100%.
10 V: Motor
secondary rated
current
0.1% –
U6-02
(52H)
Motor Excitation Current (Id)
Displays the value calculated for the motor excitation current (Id). Motor rated secondary
current is 100%.
10 V: Motor
secondary rated
current
0.1% –
U6-05
(59H)
Output Voltage Reference (Vq)
Output voltage reference (Vq) for the q-axis.
10 V: 200 Vrms
<18> 0.1 Vac –
U6-06
(5AH)
Output Voltage Reference (Vd)
Output voltage reference (Vd) for the d-axis.
10 V: 200 Vrms
<18> 0.1 Vac –
U6-21
(7D5H)
Offset Frequency
Displays the frequency added to the main frequency reference.
– 0.1% –
No. (Addr.) Name Description
Analog Output
Level
Unit Page
U8-01 to
U8-10
(1950H to
1959H)
DriveWorksEZ Custom
Monitor 1 to 10
DriveWorksEZ Custom Monitor 1 to 10
10 V: 100% 0.01% –
U8-11 to
U8-13
(195AH to
195CH)
DriveWorksEZ Version
Control Monitor 1 to 3
DriveWorksEZ Version Control Monitor 1 to 3
No signal output
available
––
All Modes
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
