B.6 Defaults by Drive Model Selection (o2-04)
402 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
No. Name Unit Default Settings
Model CIMR-E – 4A0023 4A0031 4A0038 4A0044 4A0058 4A0072 4A0088
o2-04 Drive Model Selection Hex. 9A 9C 9D 9E 9F A1 A2
E2-11 Motor rated Output kW 11 15 18.5 22 30 37 45
b3-04 V/f Gain during Speed Search % 100 100 100 100 100 100 100
b3-06 Output Current 1 during Speed Search – 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value – 140.88 126.26 115.74 103.58 92.54 76.32 71.56
C6-02Carrier Frequency Selection –7777777
E2-01 Motor Rated Current A 19.9 26.5 32.9 38.6 52.3 65.6 79.7
E2-02 Motor Rated Slip Hz 1.7 1.6 1.67 1.7 1.8 1.33 1.6
E2-03 Motor No-Load Current A 5.6 7.6 7.8 9.2 10.9 19.1 22
E2-05 Motor Line to Line Resistance Ω 0.922 0.55 0.403 0.316 0.269 0.155 0.122
E2-06 Motor Leakage Inductance % 19.6 17.2 20.1 23.5 20.7 18.8 19.9
E2-10 Motor Iron Loss for Torque Compensation W 385 440 508 586 750 925 1125
E5-01 Motor Code Selection Hex. 123B 123D 123E 123F 1240 1242 1243
L2-02Momentary Power Loss Ride-Thru Time s1222222
L2-03 Momentary Power Loss Minimum Baseblock Time s 0.9 1 1 1 1.1 1.1 1.2
L2-04 Momentary Power Loss Voltage Recovery Time s 0.3 0.6 0.6 0.6 0.6 0.6 0.6
L3-24 Motor Acceleration Time for Inertia Calculations s 0.265 0.244 0.317 0.355 0.323 0.32 0.387
L8-02 Overheat Alarm Level °C 115 120 120 115 120 120 110
L8-35Installation Method Selection –2222000
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10 10
No. Name Unit Default Settings
Model CIMR-E – 4A0103 4A0139 4A0165 4A0208 4A0250 4A0296 4A0362
o2-04 Drive Model Selection Hex. A3 A4 A5 A6 A7 A8 A9
E2-11 Motor rated Output kW 55 75 90 110 132 160 185
b3-04 V/f Gain during Speed Search % 80 60 60 60 60 60 60
b3-06 Output Current 1 during Speed Search – 0.5 0.7 0.7 0.7 0.7 0.7 0.7
b8-04 Energy Saving Coefficient Value – 67.2 46.2 38.91 36.23 32.79 30.13 30.57
C6-02Carrier Frequency Selection –7777777
E2-01 Motor Rated Current A 95 130 156 190 223 270 310
E2-02 Motor Rated Slip Hz 1.46 1.39 1.4 1.4 1.38 1.35 1.3
E2-03 Motor No-Load Current A 24 36 40 49 58 70 81
E2-05 Motor Line to Line Resistance Ω 0.088 0.092 0.056 0.046 0.035 0.029 0.025
E2-06 Motor Leakage Inductance % 20 20 20 20 20 20 20
E2-10 Motor Iron Loss for Torque Compensation W 1260 1600 1760 2150 2350 2850 3200
E5-01 Motor Code Selection Hex. 1244 1245 1246 1247 1248 1249 124A
L2-02Momentary Power Loss Ride-Thru Time s2222222
L2-03 Momentary Power Loss Minimum Baseblock Time s 1.2 1.3 1.5 1.7 1.7 1.8 1.9
L2-04Momentary Power Loss Voltage Recovery Times1111111
L3-24 Motor Acceleration Time for Inertia Calculations s 0.317 0.533 0.592 0.646 0.673 0.777 0.864
L8-02 Overheat Alarm Level °C 120 130 130 120 120 125 130
L8-35Installation Method Selection –0000000
n1-03 Hunting Prevention Time Constant ms 10 30 30 30 30 30 30
