YASKAWA E1000 - Page 51

2.2 Mechanical Installation
Mechanical Installation
2
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 51
Table 2.5 Dimensions for IP20/NEMA 1, UL Type 1 Enclosure: 400 V Class
0110
3
<2>
254 534 258 195 400 385 7.5 134 100 2.3 2.3 M6 23
0138 279 614 258 220 450 435 7.5 164 100 2.3 2.3 M6 28
0169 329 730 283 260 550 535 7.5 180 110 2.3 2.3 M6 41
0211 329 730 283 260 550 535 7.5 180 110 2.3 2.3 M6 42
0250 456 960 330 325 705 680 12.5 255 130 3.2 3.2 M10 83
0312 456 960 330 325 705 680 12.5 255 130 3.2 3.2 M10 88
0360 504 1168 350 370 800 773 13 368 130 4.5 4.5 M12 108
<1> Removing the top protective cover from a IP20/NEMA 1, UL Type 1 drive voids NEMA 1, UL Type 1 protection but still keeps IP20
conformity.
<2> Special order required. Contact your Yaskawa sales representative.
Drive Model
CIMR-E4A
<1> Removing the top protective cover from a IP20/NEMA 1, UL Type 1 drive voids NEMA 1, UL Type 1 protection but still keeps IP20
conformity.
<2> Special order required. Contact your Yaskawa sales representative.
Dimensions (mm)
Figure W H D W1 H0 H1 H2 H3 D1 t1 t2 d
Weight
(kg)
0002
1
<1>
140 260 147 122 – 248 6 – 38 5 – M5 3.2
0004 140 260 147 122 – 248 6 – 38 5 – M5 3.2
0005 140 260 147 122 – 248 6 – 38 5 – M5 3.2
0007 140 260 164 122 – 248 6 – 55 5 – M5 3.4
0009 140 260 164 122 – 248 6 – 55 5 – M5 3.5
0011 140 260 164 122 – 248 6 – 55 5 – M5 3.5
0018 140 260 167 122 – 248 6 – 55 5 – M5 3.9
0023 140 260 167 122 – 248 6 – 55 5 – M5 3.9
0031 180 300 167 160 – 284 8 – 55 5 – M5 5.4
0038 180 300 187 160 – 284 8 – 75 5 – M5 5.7
0044 220 350 197 192 – 335 8 – 78 5 – M6 8.3
0058
3
<2>
254 465 258 195 400 385 7.5 65 100 2.3 2.3 M6 23
0072 279 515 258 220 450 435 7.5 65 100 2.3 2.3 M6 27
0088 329 630 258 260 510 495 7.5 120 105 2.3 3.2 M6 39
0103 329 630 258 260 510 495 7.5 120 105 2.3 3.2 M6 39
0139 329 730 283 260 550 535 7.5 180 110 2.3 2.3 M6 45
0165 329 730 283 260 550 535 7.5 180 110 2.3 2.3 M6 46
0208 456 960 330 325 705 680 12.5 255 130 3.2 3.2 M10 87
0250 504 1168 350 370 800 773 13 368 130 4.5 4.5 M12 106
0296 504 1168 350 370 800 773 13 368 130 4.5 4.5 M12 112
0362 504 1168 350 370 800 773 13 368 130 4.5 4.5 M12 117
Drive Model
CIMR-E2A
Dimensions (mm)
Figure W H D W1 H0 H1 H2 H3 D1 t1 t2 d
Weight
(kg)
